MTG200

MTG200 Cost-effective VoIP Trunk Gateway

MTG200 series Digital VoIP Gateways with 1/2/4 ports E1/T1 simply migrate your legacy PSTN networks (legacy PBX or E1/T1 service providers) , to VoIP network. Only small investment, you can enjoy the real benefits of VoIP, and retain your PSTN connectivity. It is a compact box designed for SMEs and open-source market, fully compatible with Asterisk / Elastix / Trixbox / Freeswitch and mainstream VoIP platform. With support of ISDN PRI / SS7 / R2 MFC, integrating with your legacy PBX or PSTN network is also so easy.

Get a Quote

E1/T1
T.38/T.30
PRI
SS7
NGN/IMS
SNMP

Cost-effective VoIP Trunk Gateway for SMEs

Up to 60 simultaneous calls
Flexible routing
Multiple SIP trunks
Fully compatible with Asterisk, FreeSWITCH and mainstream VoIP platforms

Rich Experiences on PSTN Protocols

ISDN PRI

ISDN SS7 (optional)

R2 MFC

T.38 and Pass-through fax

Support modem and POS machines

More than 10-year experiences to integrate with a wide range of Legacy PBXs / Service providers' PSTN networks

Easy Management

Intuitive Web interface
Support SNMP
Automated provisioning
Dinstar Cloud Management System
Configuration Backup & Restore
Advanced Debug tools

05831726

Product Features

1/2E1/T1 Ports
2 GE
SIP v2.0
SIP-T
SIP/IMS Registration :with up to 256 SIP Accounts
NAT: Dynamic NAT, Rport
Local/Transparent Ring Back Tone
Overlapping Dialing
Dialing Rules，with up to 2000

Voice Codecs Group
Access Rule Lists
Radius
Voice Codecs:G.711a/μ law, G.723.1, G.729AB, iLBC,AMR
Silence Suppression
CNG,VAD,Jitter Buffer
Echo Cancellation (G.168),with up to 128ms
T.38 and Pass-through
Support Modem/POS
DTMF Mode: RFC2833/SIP Info/In-band

VLAN 802.1p/q
ISDN PRI, Q.sig
ISDN SS7
R2 MFC
Web GUI Configuration
Data Backup/Restore
PSTN Call Statistics
SIP Trunk Call Statistics
Firmware Upgrade via TFTP/Web
SNMP v1/v2/v3
Network Capture
Syslog: Debug, Info, Error, Warning , Notice
Call History Records via Syslog
NTP Synchronization
Centralized Management System

All Parameters Product Comparison
